Jenbacher Type 2

Jenbacher Type 4

Based on the proven design concepts of Jenbacher Type 3 and Type 6 engines, Type 4 engines are characterized by high power density and outstanding efficiency.

Enhanced control and monitoring provide easy maintenance capabilities, as well as excellent reliability and availability.
>6,400 engines delivered since 2002.

    • Front View Jenbacher J420 D/E Gas Engine_New
    • Front View of a Jenbacher J420 Gas Engine
    • Front View of a Jenbacher J416 Gas Engine
    • Front View of a Jenbacher J412 Gas Engine
    • Front View Jenbacher J420 D/E Gas Engine_New (CHP)
    • Front View of a Jenbacher J420 Gas Engine (CHP Module)
    • Front View of a Jenbacher J416 Gas Engine (CHP Module)
    • Front View of a Jenbacher J412 Gas Engine (CHP Module)
    • J320 CONTAINER 1
    • J320 CONTAINER 2
    • J320 CONTAINER 3

Change the scope of supply by clicking on a thumbnail.

Scope of supply:

50 Hz

60 Hz

* Provided technical data is for information only. Data ranges are calculated considering various gas quality levels and ambient conditions (standard or hot/tropical conditions, etc.).
Jenbacher can change the technical data unilaterally. In the case of such change, we will update the data on our pages as soon as we can.
Please reach out to our experts to get help with engines selection, obtain the technical parameters for your gas composition.



Output and efficiency at generator terminals. Energy input is according to DIN ISO 3046 and DIN 6271, respectively, with a tolerance of + 5%.
All data according to full load and subject to technical development and modification.
Based on emission values of 250 and 500 mg/Nm3 NOx at 5% O2 at dry exhaust gas.
Base for biogas and sewage gas versions: 65% CH4 / 35% CO2.
Base for landfill gas version: 55% CH4 / 40% CO2 / Rest N2.

Electrical Output851 - 1,564 kW

Thermal Output916 - 1,775 kW

Voltage480V - 13.8kV

Electrical Efficiencyup to 42.7 %

Thermal Efficiencyup to 48.0 %

Highlights of Jenbacher Type 4 engines

Jenbacher Type 4 engines have the same design, emissions control, and waste gas-to-energy capabilities as their Type 2 and Type 3 counterparts, plus high power density and outstanding efficiency in their power range.

  • The high-power turbocharger allows optimal operation at higher air intake temperature and altitude.
  • A four-valve cylinder heads features enhanced swirl and channel geometry using advanced calculation and simulation methods, resulting in optimal cooling and combustion conditions.
  • The Type 4’s connecting rod reduces bearing wear and is easy to maintain.

Applicable gas types include: natural gas, associated petroleum gas (flare gas), propane, biogas, sewage gas, landfill gas, coal mine gas, other special gases (e.g. coke, wood, and pyrolysis gases).

Scope of supply:

Combined Heat and Power Module (CHP Module) solutions allow customers to generate power and heat simultaneously at a very high total efficiencies, reaching 90% and even more.

Usual scope of supply:

  • Engine and alternator installed on the frame
  • Control panel, gas train
  • Heat exchangers including exhaust gas heat exchanger

CHP Modules can generate hot water or steam at various parameters and can be integrated with your existing heat infrastructure. You can select the option that fits your project’s needs among the various heat recovery schemes provided by Jenbacher.

The scope of supply can be extended further with various balance of plant options (BOP), reach out to our specialists for help in selecting scope of supply and BOP options to fulfill your project’s needs.

CHP Modules can be installed inside a building or inside a container. To see more details about Jenbacher’s containerized solutions, click here.

Balance of Plant (BOP)

The right auxiliary equipment is of critical importance in ensuring that a power solution is economically feasible and provides your business with reliability, availability, and efficiency. Click on the provided BOP options to learn more.
Reach out to our experts to select the configuration that fits your business’ needs.

Available BOP elements may vary, depending on the engine and application type.

  • Proven Efficiency

    Offering superior efficiency with an innovative engine concept, Type 4 engines save on fuel without sacrificing flexibility or reliability.

  • The flexibility to do more

    The Type 4 is available in 50 and 60 Hz and features fuel and solution flexibility—making it an excellent choice for more than 10 different applications.

  • Reliability you can count on

    With their reliability, dependability and high degree of availability, it’s easy to see why over 2,000 Type 4 engines have been delivered.

Customer-only Resources

folder

Get access to almost 2,000 Resources (such as Drawings, Service Technician Instructions, User Manuals, & more…) for Jenbacher Gas Engines with our dedicated Portal which includes advanced (yet easy to use!) search capabilities to find what you’re looking for.

newsletter

Subscribe to our monthly Services Newsletter and additional materials to stay up-to-date with the latest Jenbacher technical news.

If you already have
an access, please LOG IN

or

Contact Us to Sign-up

Contact Us to Sign-Up

Type 4 Case studies

slide-project-america
  • CS Hyosung - Foto

    Hyosung (KOR)

    DECARBONIZING HEAVY INDUSTRY
    with Asia Pacific’s first 100% hydrogen engine power plant

    Location

    Ulsan, South Korea

    Installed engines

     1 x J420

    Electrical output

     up to 1,042 MW

    Thermal output

     1,136 MW

    Energy source

    100% hydrogen

    Commissioned

    2024

  • CS La Cira - Foto

    La Cira (COL)

    TURNING FLARE GAS INTO POWER
    for lower energy costs, greater reliability, and reduced emissions

    Location

    La Cira, Colombia

    Installed engines

     11 x J420

    Electrical output

     14.6 MW

    Electrical efficiency

     40.8%

    Energy source

    Flare gas

    Commissioned

    2016, 2022

  • Case Study Mavrorachi - Foto

    Mavrorachi Landfill (GRC)

    USING LANDFILL GAS FOR POWER GENERATION TO LOWER GREENHOUSE GAS EMISSIONS
    Sustainable HELECTOR project with Jenbacher engines in Greece wins global environmental award

    Location

    Thessaloniki, Greece

    Installed engines

     3 x J416

    Electrical output

     3.52 MW

    Electrical efficiency

     42%

    Energy source

    Landfill gas

    Commissioned

    2020

  • CS Agrotor - Foto

    Agrotor (HND)

    HONDURAN EDIBLE VEGETABLE OIL EXTRACTION PLANT
    uses waste byproduct for power generation

    Location

    San Alejo, Atlantida, Honduras

    Installed engines

     1 x J420, 1 x J316

    Electrical output

     2,272 kW

    Total efficiency

     up to 40.1%

    Energy source

    Biogas

    Commissioned

    2019, 2008

  • Hychico Scheme

    Hychico (ARG)

    JENBACHER J420 ENGINE HARNESSES THE PROMISE
    of global renewable energy with hydrogen

    Location

    Chubut province, Argentina

    Installed engine

    1 x J420

    Electrical output

    1.4 MW

    Energy source

    Pipeline gas with up to 42% (V) H2

    Commissioned

    2008
